Draping Simulation Smart Regeneration
Creo+
User Interface Location: In the Composite environment, click
Draping Simulation.
Draping Simulation.Description
The regeneration process for the draping simulation feature is now significantly optimized to leverage the Drape over underlying plies option.
When you modify a ply, the plies that are draped with the Drape over underlying plies option selected, are regenerated in the draping simulation feature only when the plies are geometrically above the modified ply and overlap it.
This smart regeneration ensures that only the necessary plies are regenerated in the draping simulation preventing unnecessary regenerations. This makes the process more efficient and improves the regeneration performance.
Benefits
This enhancement improves productivity and user experience by reducing regenerations in the draping simulation feature.
Additional Information
Tips: | None. |
Limitations: | No known limitations. |
Does this replace existing functionality? | No. |
Configuration option associated with this functionality: | None. |
